VIRIDYN DX
Corrosion Resistant, Hard (7H-9H), Hydrophobic
VIRIDYN DX creates a hard (7H - 9H), transparent, low-surface energy shell. Formulated for hydrophobicity and corrosion resistance, while offering low-grade oil repellence. VIRIDYN DX is Fluorocarbons-free and PFAS-free.
Key Features & Benefits
Hydrophobic: Repels water (contact angle > 100 degrees).
Low-Grade Oil Repellence: Can be used to achieve oleophobicity grades 1 to 2.
Easy Application & Reapplication: Fast-curing, one-step system for consistent performance in the field.
High Durability: Ensures surface protection against harsh tactile environments.
RF-Transparency: VIRIDYN DX coatings allow radio frequency signals to pass through with minimal interference.
Chemical & Solvent Resistant: Impermeable to gas and corrosive pollutants. Protects the substrate. Does not decrease porosity of membranes.
Fluorocarbons & PFAS-Free
Major Applications
Laboratory & Medical Devices: Used for coating plastic laboratory devices and microfluidic devices.
Membranes & Filtration: Maintains air permeability, Rayl values, and acoustic penetrance in fabrics, mesh, filters, and membranes.
Precision Components: Suitable for MR heads and other sensitive electronic parts.
-
Chemistry: Hydrocarbon siloxane
Form: Liquid
Color: Clear - lightly turbid
Solvent options: Ethyl Acetate, Tert Butyl Acetate, or AS300
Solids: percent 4% to 40%
Specific gravity: 0.8 g/ml
Flammability risk: Solvents Ethyl Acetate and Tert Butyl Acetate are flammable. AS300 is not flammable
Soluble in Water: No
Dry film toxicity: Non-toxic and non-flammable
Temperature stability: > 500 degrees centigrade
Odor: Dry film has no odor
Film Hardness: 7H – 9H pencil lead hard
Refractive Index: ~1.4
Water contact angle: >100 degrees
Water roll-off: <40 degree roll-off angle
Mineral oil: contact angle >20 degrees
Mineral oil roll-off: <5 degree roll-off angle
UV light resistance: No yellowing observed
